On-grid Solar power Inverter 50KW 60KW 80KW 100KW

Sunbuntal supply50KW 60KW 80KW 100KW hybird Solar Power System for Industrial or Commercial use

Green, energy saving and environmental protection, easy to install.

Type: on grid

Power : 50KW 60KW 80KW 100KW

Certificate : ISO, CE

Lead Time : 15 Days

Product Origin: shenzhen China

Shipping Port: shenzhen port

contact now

Items	BTON50K	BTON60K	BSM80K-BHV
DC Input
Max. PV input voltage	1000Vdc		1100Vdc
Rated PV voltage	710Vdc	740Vdc	800Vdc
Max. PV input current	120A (12×10A)	120A (12×10A)	176A (16×11A)
No. of MPPTs	4	4	4
No.of PV strings per MPPT	3/3/3/3	3/3/3/3	4/4/4/4
MPPT voltage range	300V~1000V
Starting voltage	250Vdc
AC Output
Rated AC output power	50kW	60kW	80kW
Max. output power	55kVA	66kVA	88kVA
Rated AC output voltage	480Vac		540Vac
Rated output current	57.7A	72.2A	85.5A
Max. output current	63.5A	79.4A	94.1A
Rated grid frequency	50Hz/60Hz
Grid frequency range	45~55Hz/55~65Hz
Power factor	>0.99 (full load)
Adjustable power factor	0.8 (leading)-0.8 (lagging)
THDi	<3% (rated power)
Efficiency
Max. efficiency	98.80%		99%
European efficiency	98.49%	98.49%	98.50%
General
Dimensions (W×H×D)	600×860×294mm
Weight	64kg			76kg
IP grade	IP65
Noise level	<65dB
Self-consumption at night	<1W
Cooling type	Intelligent forced air cooling
Altitude	5000m (>3000m derating)
Operating temperature	-25ºC~+60ºC(>45ºC derating)
Relative humidity	0~95% (Non-condensation)
Display	LCD+LED
Communication	RS485/WIFI/GPRS		RS485/WiFiGPRS/PLC
DC terminal	MC4 Terminal
AC terminal	OT Terminal
Installation method	Wall-mounted
